GENERAL DESCRIPTION
SERVICE BRAKES
35A-3
SPECIFICATIONS
ITEM SPECIFICATION
Master
cylinder
Type Tandem type
I.D. mm (in) 26.9 (1.06)
Brake
booster
Type Vacuum type, tandem
Effective dia. of power cylinder
mm (in)
205 + 230 (8.07 + 9.06)
Boosting ratio 4.5 <Brake pedal depressing force: 230 N (51.7 lb)>
Rear wheel hydraulic control method Electronic brake-force distribution (EBD)
Front brakes Type 4-opposed piston, ventilated disc
Disc effective dia × thickness
mm (in)
263 × 32 (10.4 × 1.3)
Wheel cylinder I.D. mm (in) 40.0 (1.58) × 2, 46.0 (1.81) × 2
Pad thickness mm (in) 10.0 (0.39)
Clearance adjustment Automatic
Rear brakes Type 2-opposed piston, ventilated disc
Disc effective dia × thickness
mm (in)
252 × 22 (9.9 × 0.9)
Wheel cylinder I.D. mm (in) 40.0 (1.58) × 2
Pad thickness mm (in) 9.0 (0.35)
Clearance adjustment Automatic
Brake fluid DOT3 or DOT4
