BUMPER
EXTERIOR
51-3
BUMPER
GENERAL INFORMATION
M2510000100592
A large front bumper integrated with radiator grill and
a rear bumper integrated with rear under spoiler
have been adopted for better aerodynamic perfor-
mance. A cooling hole for the intercooler is in the
center of the front bumper. The front license plate
mount is offset from the center to the left side to
improve the cooling performance of the intercooler.
CONSTRUCTION DIAGRAM
AC210166
FRONT BUMPER REAR BUMPER
AB
