SEAT BELT
INTERIOR
52A-7
SEAT BELT
M2520010000111
FRONT SEAT BELT
• An ELR three-point seat belt (driver's side) and
three-point seat belt with ELR/ALR changeover
mechanism (passenger's side) is used.
• One-touch push button style adjustable seat belt
anchor and retractable buckle provide the most
suitable belt fitting.
• The seat belt retractor with the force limiter for
the driver’s seat and the front passenger’s seat
increase safety.
• A seat belt warning light is installed to the driver’s
seat.
REAR SEAT BELT
• 3-point seat belt with Automatic Locking Retrac-
tor (ALR)/ELR changeover mechanism (LH/RH/
Center) is used for the rear seat.
AC209722
3-POINT SEAT BELT WITH ELR/ALR
CHANGEOVER MECHANISM
ONE-TOUCH PUSH BUTTON
STYLE ADJUSTABLE
SEAT BELT ANCHOR
AB
SEAT BELT WARNING LIGHT
SEAT BELT RETRACTOR
SEAT BELT RETRACTOR
WITH THE FORCE LIMITER
SEAT RETRACTABLE
BUCKLE
ELR 3-POINT
SEAT BELT
3-POINT SEAT BELT WITH ELR/ALR
CHANGEOVER MECHANISM
