FRONT DISC BRAKE
SERVICE BRAKES
35A-5
FRONT DISC BRAKE
M2350003000141
Brakes with the following specifications have been
adopted for the front brakes.
• Bremboä V7-Z4046 4-opposed-piston ventilated
discs
• An outer disc method in which the wheels and
discs are tightened together is used to improve
the ease of brake disc removal and installation.
• The brake pads are equipped with mechanical-
type audible wear indicators to notify the driver
when the usage limit [2 mm (0.08 in)] is reached.
• Split fins adopted as the disc fins to improve cool-
ing performance
NOTE: Bremboä is an italian brake component
maker whose name and products are well known in
the motorsports world.
DISC BRAKE NOMENCLATURE
AC211388
AB
FRONT OF VEHICLE
PADS
1
V7–Z40 46
2
34
AC211390
NO. ITEM CONTENT
1 Brake disc type V: Ventilated
2 Brake size
(Minimum applicable
disc wheel)
7: 17-inch
3 No. of pistons Z: 4-piston (opposed
type)
4 Piston size (rounded
to nearest integer)
40: φ40 mm (1.6 in)
46: φ46 mm (1.8 in)
To Next Page
