GENERAL DESCRIPTION
SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
52B-4
SRS SYSTEM CIRCUIT DIAGRAM
AC211582
MICRO
PROCESSOR
FRONT AIR
BAG
ANALOG
G-SENSOR
CONNECTOR
LOCK
DETECTION
CIRCUIT
CONNECTOR
LOCK
DETECTION
CIRCUIT
SCAN TOOL
INTERFACE
CIRCUIT
BACK UP
CAPACITOR
DC-DC
CONVERTER
POWER
SOURCE
CIRCUIT FOR
SIDE-AIRBAG
FRONT AIR BAG
SAFING
G-SENSOR
WARNING
LIGHT
DRIVE
CIRCUIT
AIR BAG
DRIVE
CIRCUIT
AIR BAG
DRIVE
CIRCUIT
AIR BAG
DRIVE
CIRCUIT
AIR BAG
DRIVE
CIRCUIT
AIR BAG
DRIVE
CIRCUIT
AIR BAG
DRIVE
CIRCUIT
AIR BAG
DRIVE
CIRCUIT
AIR BAG
DRIVE
CIRCUIT
FRONT
IMPACT
SENSOR
INTERFACE
CIRCUIT
DATA LINK
CONNECTOR
(FOR SCAN
TOOL)
ON
ON
OFF
OFF
CONNECTOR
LOCK SWITCH*
IGNITION SWITCH (IG1)
No.2
7.5A
No.3
7.5A
COMBINATION
METER (SRS
WARNING LIGHT)
ON
ON
OFF
OFF
CONNECTOR LOCK
SWITCH*
DRIVER'S
AIR BAG
MODULE
CLOCK SPRING
ON
OFF
OFF
OFF
ON
ON
PASSENGER'S
(FRONT) AIR BAG
MODULE
OFF
ON
OFF
ON
CONNECTOR
LOCK SWITCH*
OFF
ON
OFF
ON
CONNECTOR
LOCK SWITCH*
SEAT BELT
PRE-TENSIONER
(LH)
SEAT BELT
PRE-TENSIONER
(RH)
OFF
ON
OFF
CONNECTOR
LOCK SWITCH*
(LH) (RH)
FRONT IMPACT
SENSOR
CONNCTOR LOCK
SWITCH*
AB
ON
OFF
NOTE
*: CONNECTOR LOCKED: ON
CONNECTOR UNLOCKED: OFF
