FUNCTIONS AND CONTROL OF SWS ECUS
SIMPLIFIED WIRING SYSTEM (SWS)
54B-18
Headlight automatic-shutdown
function
When the passing switch is turned ON for more than two seconds with the
auto-light switch ON and the turn signal light switch turned to RH, the
headlight automatic-shutdown function is switched between available and
unavailable.
• Function not available: Tone alarm sounds twice.
• Function available: (when the taillight illuminates with the ignition switch
turned to the "LOCK" (OFF) position, it is not automatically turned off):
Tone alarm sounds three times. (Initial state)
Delayed light-off time of the
dome light
When the turn signal light switch is set in the order of RH to LH to RH to LH
within three seconds from the LH position, the delayed light-off time is
changed as follows:
a. 30 seconds: Tone alarm sounds once. (Initial state)
b. 10 seconds: Tone alarm sounds twice.
c. 0 seconds (No delay time): Tone alarm sounds three times.
d. 15 seconds: Tone alarm sounds four times.
e. 7.5 seconds: Tone alarm sounds five times.
f. Returns to a after e, and repeats from a in order.
Interior light automatic-
shutdown function
When the hazard light switch is turned ON for more than two seconds, the
interior light cut-off function is changed as follows: (a and b switches
alternately)
a. Function available: Tone alarm sounds once. (Initial state)
b. Function not available: Tone alarm sounds twice.
Initialization of all functions
(Return to initial settings)
When the windshield washer switch is ON for more than 20 seconds
continuously, the tone alarm sounds twice, and all functions will be
initialized. (Settings are returned to their initial states.) The configuration
mode entry tone alarm sounds after 10 seconds. However, to initialize all
functions, the windshield washer switch must stay ON for 20 seconds.
When the windshield washer switch is ON for more than 20 seconds
continuously without the configuration mode set, the configuration mode
will be set after 10 seconds without the initialization of all functions.
FUNCTION CONFIGURATION PROCEDURE
