ON-BOARD DIAGNOSTICS
MULTIPORT FUEL SYSTEM (MFI)
13A-12
.
Data List Function
The data list items are shown in the following table.
NOTE: Data list items consist of MUT-II/III items and GST items. GST items can be accessed through the use
of a general scan tool.
NOTE: When MUT-II/III is used, MUT-II/III items appear alphabetically; then, GST items appear alphabeti-
cally. The black and white characters of the GST items are inverted from the MUT-II/III items.
MUT-II/III Item
GST Item
P0830 Clutch pedal position switch circuit range/ performance
−
P1400 Manifold differential pressure sensor circuit malfunction
×
P1603 Battery backup circuit malfunction
×
P2066 Fuel level sensor circuit range/performance (sensor 2)
×
P2263 Intake charge system malfunction
−
DTC DIAGNOSTIC ITEM MIL ITEM
MUT-II/III SCAN TOOL
DISPLAY
ITEM NO. INSPECTION ITEM UNIT
A/C RELAY 49 A/C compressor clutch relay ON/OFF
A/C SWITCH 28 A/C switch ON/OFF
BARO SENSOR 25 Barometric pressure sensor kPa (in.Hg)
BATT VOLTAGE 16 Power supply voltage V
CKP SENSOR 22 Crankshaft position sensor r/min
CRANK. SIGNAL 18 Cranking signal (ignition switch-ST) ON/OFF
ECT SENSOR 21 Engine coolant temperature sensor
°C (°F)
FUEL TEMP 4A Fuel tank temperature sensor
°C (°F)
HO2S BANK1 S1 11 Heated oxygen sensor (front) mV
HO2S BANK1 S2 59 Heated oxygen sensor (rear) mV
IAC VALVE POS 45 Idle air control (stepper) position STEP
IAT SENSOR 13 Intake air temperature sensor
°C (°F)
IG. TIMING ADV 44 Ignition coils and ignition power transistor
°BTDC
INJECTOR 41 Injectors mS
MDP SENSOR 95 Manifold differential pressure sensor kPa (in.Hg)
PSP SWITCH 27 Power steering pressure switch ON/OFF
TANK PRS. SNSR 73 Fuel tank differential pressure sensor kPa (in.Hg)
TP SENSOR 14 Throttle position sensor mV (%)
VAF SENSOR 12 Volume airflow sensor (mass airflow rate) Hz (gm/s)
MUT-II/III SCAN TOOL
DISPLAY
ITEM NO. INSPECTION ITEM UNIT
ECT SENSOR 21 Engine coolant temperature sensor
°C (°F)
ENGINE LOAD 2 87 Calculated load value %
ENGINE SPEED 22 Crankshaft position sensor r/min
HO2S BANK1 S1 A1 Heated oxygen sensor (front) V
