AIR INTAKE SYSTEM
INTAKE AND EXHAUST
15-2
AIR INTAKE SYSTEM
AIR DUCT AND AIR CLEANER
M2150004000032
.
• Unrestricted fresh ambient air enters from above
the radiator, engine performance has been
enhanced and intake air noise has been reduced.
• The air cleaner is made from recycled paper
mixed with plastic to reduce industrial wastes and
protect the environment.
• Environmentally-friendly unleaded rubber materi-
als are used for the air intake hose.
CONSTRUCTION DIAGRAM
CHARGE AIR COOLER
M2150007000019
By mounting an air cooled charge air cooler to
reduce the intake air temperature after boosting,
engine output has been improved.
CONSTRUCTION DIAGRAM
AC210029
AIR DUCT
AIR INTAKE HOSE
AIR CLEANER ASSEMBLY
AB
AC210030
AIR BY-PASS VALVE
AB
CHARGE AIR COOLER
AIR HOSE AND PIPE
AIR HOSE AND PIPE
To Next Page
