AIR INTAKE SYSTEM
INTAKE AND EXHAUST
15-4
SYSTEM DIAGRAM
JOINT
CONNECTOR (3)
CHARGE
AIR COOLER
WATER SPRAY
SWITCH
RHEOSTAT
JOINT
CONNECTOR (1)
RELAY
BOX
FRONT-ECU
TAILLIGHT
RELAY
ENGINE
CONTROL
MODULE
JUNCTION
BLOCK
CHARGE
AIR COOLER
WATER SPRAY
RELAY
CHARGE
AIR COOLER
WATER SPRAY
MOTOR
IGNITION
SWITCH (IG2)
JOINT
CONNECTOR (2)
IGNITION
SWITCH (IG1)
JUNCTION
BLOCK
JOINT
CONNECTOR (4)
COMBINATION
METER
AC210034
