FX2N Series Programmable Controllers Index 8
8-3
ENG
A AC powered base units
FX
2N units ................................................. 1-4
Approvals..................................................... viii
B Base units
AC powered (relay/transistor output) ........ 1-4
DC powered (relay/transistor output) ........ 1-4
FX
2N physical features.............................. 3-4
110V AC input specification ..................... 5-9
Relay output specification ........................ 6-3
Terminal layout FX
2N (relay opt, 24V DC
inp) ........................................................ 2-4
Terminal layout FX
2N (transistor opt,
DC inp) ..................................................... 2-5
Transistor output specifications ................ 6-9
Triac output specification ........................ 6-6
Basic diagnostics ....................................... 7-4
BATT.V LED ON ....................................... 7-6
Common error ........................................ 7-12
CPU.E LED ON ........................................ 7-9
Error codes ............................................. 7-19
Error flags ............................................... 7-15
Error registers ........................................ 7-17
Power ON, PC OFF ................................. 7-4
PROG.E LED flashes ............................... 7-8
C Cable size
Earth/grounding cables .......................... 4-10
Power cables ............................................ 4-6
Common errors ........................................ 7-12
D Diodes in series with inputs ....................... 5-7
E Environmental
Caution ................................................... 3-10
Mounting in an enclosure ......................... 3-9
PC specification ....................................... 3-8
Error codes ............................................... 7-19
Error flags ................................................. 7-15
Error registers .......................................... 7-17
Extension blocks ........................................ 1-5
Terminal layouts - all types ....................... 2-7
Extension units
See Powered extension units
G General features
FX
2N units ................................................ 3-4
I In-rush currents when using triac outputs ... 6-7
Input specification
110V AC FX
0N ........................................ 5-10
Programming caution when using
110V AC in-puts .................................... 5-12
24V DC FX
2N ........................................... 5-3
Using diodes in series with inputs ............ 5-7
Using resistors in parallel to inputs .......... 5-8
Wiring 110V AC inputs ............................5-11
Wiring an input for sink ............................ 5-6
Wiring an input for source ........................ 5-6
Installation .................................................. 3-3
Instruction list
Alphabetically sorted .............................. 7-22
Numerically sorted ................................. 7-21
M Maintenance
General maintenance .............................7-14
Replacing the battery .............................7-13
Model name
Explanation ..............................................1-10
Mounting
DIN rail caution ....................................... 3-11
General notes with regard to electrical
noise .....................................................3-13
In an enclosure .........................................3-9
Use of DIN rail ........................................ 3-11
Use of direct mounting ...........................3-12
O Output specification
In-rush currents ........................................6-7
Relay outputs ...........................................6-3
Reliability ..................................................6-4
Response times ......................................6-10
Transistor outputs......................................6-9
Triac outputs .............................................6-6
Wiring a relay ...........................................6-5
Wiring a transistor .................................. 6-11
Wiring a triac ............................................6-8
P Power supply
24V DC service supply 4-11 ................... 4-11
Cable size .................................................4-6
Connection diagram .................................4-9
System isolation .......................................4-6
System requirements ...............................4-8
Powered extension units
All types.....................................................1-5
Terminal layouts - all types .......................2-7
Preliminary checks .....................................7-3
R Relay reliability ...........................................6-4
Replacing the battery ...............................7-13
Resistors in parallel with inputs ..................5-8
Response times when using transistors....6-10
S Safe loads ................................................6-12
Safety
Guidelines ....................................................ii
Manual symbols ...........................................ii
Serial Number
Explanation ............................................. 1-11
Service power supply
Caution .................................................. 4-11
Special function blocks ...............................1-7
System Configuration ...............................1-12
Example .................................................1-16
T Terminal layouts
FX
0N extension blocks - all types ..............2-8
FX
2N
base unit (transistor opt, 24V DC inp) . 2-5
FX
2N
base units (relay output, 24V DC input) 2-4
FX2N extension blocks - all types .............2-7
FX
2N powered extension units - all types..2-7
Termination
Screw terinals .......................................... 4-5
U Unit accessories..........................................1-9
