FX2N Series Programmable Controllers Introduction 1
1-6
Figure 1.1:
ENG
- Dimensioned unit FRE - Dimensions
GER - Abmessungen ITL - Dimensioni
ESP - Dimensiones
Figure 1.2:
ENG - Extension block dimensions
FRE - Dimensions des modules d’extension
GER - Abmessungen der Erweiterungsmodule
ITL - Dimensioni dei moduli di ampliamento
ESP - Dimensiones de los módulos de ampliación
DIN rail : 35mm
(1.38)
87 (3.42)
90
(3.54)
UNITS: mm
(inches)
350
(13.78)
130
(5.11)
D
I
N
r
a
i
l
:
3
5
m
m
(1.38)
87 (3.42)
90
(3.54)
UNITS: mm (inches)
70
(2.76)
40
(1.57)
