FX2N Series Programmable Controllers Power Supply 4
4-8
Table 4.1:
FX
2N
-¶¶M/E- ES/ESS/E FX
2N
-¶¶M/E-DS/DSS
Power supply
100 - 240 V AC +10 % -15%,
50/60 Hz
24V DC +20%, -30%
Alimentation en tension
Spannungsversorgung
Alimentazione della tensione
Alimentación de tensión
Max. allowable momentary
power failure period
10 msec.
(10 msec. > PLC = RUN,
10 msec. < PLC = STOP )
5ms
(D8008 + -1)
Temps de panne de tension maxi
admissible
max. zulässige
Spannungsausfallzeit
Tempo max. consentito di caduta
tension
Tiempo máximo admisible de
fallodetensión
Fuse (size) rating
(∅ 5 × 20 mm (0.2 × 0.79 inches))
FX
2N-16M, 32M/E =3.15A
(type 50CT-032H)
FX
2N-48M/E, 64M, 80M, 128M = 5A
(type 50CT-050H)
Fusible (dimensions) courant
Sicherung (Maße) Strom
Fusibile (dimensioni) corrente
Fusible (dimensiones) corriente
In-rush current
FX
2N-PPM/E:
100V AC Max. 40A < 5msec,
200V AC Max. 60A < 5msec
FX
2N-128M/E:
100V AC Max. 50A < 7msec,
200V AC Max. 70A < 7msec
Valeurs de pointe de l’intensité
Stromspitzenwerte
Valori di picco della corrente
Valores punta de corriente
Power consumption
FX
2N-16M*-ES/UL =30VA
FX2N-32E*-ES/UL =35VA
FX2N-32M*-ES/UL =40VA
FX2N-48E*-ES/UL =45VA
FX2N-48M*-ES/UL =50VA
FX2N-64M*-ES/UL =60VA
FX2N-80M*-ES/UL =70VA
FX2N-128M*-ES/UL=100VA
FX2N-16M*-DS/DSS=20W
FX2N-32M*-DS/DSS=25W
FX2N-48M*-DS/DSS=30W
FX2N-48E*-DS/DSS=30W
FX2N-64M*-DS/DSS=35W
FX2N-80M*-DS/DSS=40W
Puissance absorbée
Leistungsaufnahme
Potenza assorbita
Potencia absorbida
ENG - Power requirements (all FX2N-¶¶M/E type units)
FRE
- Alimentation en tension (tous les appareils FX2N-¶¶M/E)
GER
- Spannungsversorgung (alle FX2N-¶¶M/E-Geräte)
ITL
- Alimentazione della tensione (tutti gli apparecchi FX2N-¶¶M/E)
ESP
- Alimentación de tensión (todas las unidades FX2N-¶¶M/E)
ENG
FRE
GER
ITL
ESP
ENG
FRE
GER
ITL
ESP
ENG
FRE
GER
ITL
ESP
ENG
FRE
GER
ITL
ESP
ENG
FRE
GER
ITL
ESP
