9 OUTLINE DRAWINGS
9 - 13
(c) MR-J4-350A4(-RJ)
[Unit: mm]
105
93 66
7.5 235
200
6
Approx. 80
Approx. 28
2-φ6 mounting hole
Lock knob
250
7.5
6
CNP1
CNP2
CNP3
Cooling fan exhaust
Approx. 73.5Approx. 69.3
Approx.
38.5
Intake
With
MR-BAT6V1SET
Approx.
34
Mass: 3.6 [kg]
L2
N-
P3
L11
L21
P4
L3
L1
C
D
P+
PE
Terminal
CNP1
CNP2
V
W
U
CNP3
Screw size: M4
Tightening torque: 1.2 [N•m]
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
235 ± 0.5
93 ± 0.5
Approx. 6Approx. 6
Approx.
7.5
4-M5 screw
Approx. 105
Approx. 250
Mounting hole process drawing
Approx.
7.5
