9 OUTLINE DRAWINGS
9 - 14
(d) MR-J4-500A4(-RJ)
[Unit: mm]
Approx. 200
Approx. 28
Approx. 80
Approx. 28
6 118
130
7.52357.5
250
200
Approx. 73.5Approx. 69.3
Approx.
60
Approx.
38.5
6
TE2
TE3
TE1
PE
Built-in regenerative resistor
lead terminal fixing screw
Screw size: M4
Tightening torque: 1.2 [N•m]
Cooling fan exhaust
Intake
With
MR-BAT6V1SET
Mass: 4.3 [kg]
TE1
TE2
Terminal screw: M4
Tightening torque: 1.2 [N•m]
Terminal screw: M3.5
Tightening torque: 0.8 [N•m]
PE
TE3
PE
Terminal screw: M4
Tightening torque: 1.2 [N•m]
Screw size: M4
Tightening torque: 1.2 [N•m]
N- P3 P4TE3
L2 L3L1 CP+TE1 V WU
L11 L21TE2
Terminal
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
235 ± 0.5
118 ± 0.5
Mounting hole process drawing
Approx.
7.5
Approx. 250
4-M5 screw
Approx. 130
Approx. 6Approx. 6
Approx.
7.5
