TORQUE SPECIFICATIONS
ENGINE OVERHAUL
11B-4
Alternator bolt 44 ± 10
Ignition coil bolt 10 ± 2
Spark plug 25 ± 5
Accessory bracket bolt 44 ± 8
Throttle body
Vacuum pipe assembly bolt 11 ± 1
Throttle body bolt 9.5 ± 2.5
Manifold absolute pressure (MAP) sensor screw 4.0 ± 1.0
Solenoid valve screw 4.0 ± 1.0
Water pipe bolt 10 ± 2
Inlet manifold and fuel system
Oil level gauge guide bolt 10 ± 2
Injector protector rear bolt 3.5 ± 1.5 → 20 ± 2
Delivery pipe bolt 3.5 ± 1.5 → 20 ± 2
Inlet manifold bolt and nut 3.5 ± 1.5 → 20 ± 2
Inlet manifold stay bolt 20 ± 2
Inlet manifold stay B bolt 20 ± 2
Inlet manifold stay C bolt 20 ± 2
Injector protector front bolt 3.5 ± 1.5 → 20 ± 2
Detonation sensor bolt 20 ± 2
Oil pressure switch 10 ± 2
Exhaust manifold
Exhaust manifold cover bolt 8.0 ± 2.0
Exhaust manifold nut 49 ± 5
Exhaust manifold bracket bolt (Exhaust manifold side) 56 ± 8
Exhaust manifold bracket bolt (Cylinder block side) 41 ± 10
Crank angle sensor bolt 11 ± 1
Crank angle sensor cover bolt 11 ± 1
Oxygen sensor 44 ± 5
Water hose and pipe
Water inlet fitting bolt 24 ± 3
Water outlet fitting bolt 24 ± 3
Thermostat housing bolt 24 ± 3
Engine hanger bolt 28 ± 8
Coolant temperature sensor 30 ± 9
Water pump bolt 24 ± 3
Water pipe nut 24 ± 3
Camshaft position sensor 11 ± 1
Oil pan and timing chain case
Cylinder head cover bolt 3.0 ± 1.0 → 5.5 ± 0.5
Item N⋅m
