TORQUE SPECIFICATIONS
ENGINE OVERHAUL
11B-5
Timing chain case bolt <M6> 10 ± 2
Timing chain case bolt <M8 × 10> 13 ± 1
Timing chain case bolt <M8 × 30> 24 ± 4
Oil pan bolt <M6> 10 ± 2
Oil pan bolt <M8> 31 ± 2
Air compressor bracket bolt 23 ± 6
Oil drain plug 39 ± 5
Oil filter 14 ± 2
PCV valve 2.5 ± 0.4
Engine support bracket assembly washer bolt 48 ± 6
Timing chain
Inlet V.V.T. sprocket bolt 59 ± 5
Exhaust camshaft sprocket bolt 59 ± 5
Timing chain tensioner bolt 10 ± 2
Tensioner lever bolt 10 ± 2
Timing chain guide bolt 10 ± 2
Camshaft
Oil feeder control valve (OCV) bolt 10 ± 2
Camshaft bearing cap bolt 12 ± 1
Front camshaft bearing cap bolt 17 ± 3 → 30 ± 2
Cylinder head and valves
Cylinder head bolt 35 ± 2 → +90°+90°
Oil pump chain
Drive plate bolt 40 → 130
Oil pump case bolt 26 ± 2
Oil pump sprocket bolt 23 ± 2
Oil pump tensioner lever bolt 10 ± 2
Oil pump chain guide bolt 10 ± 2
Ladder frame bolt 24 ± 2
Balancer chain
Drive plate bolt 40 → 130
Balancer shaft module bolt 20 → 44 → 0 → 20 → +135°
Balancer shaft chain tensioner bolt 10 ± 2
Lever tensioner bolt 10 ± 2
Balancer shaft chain guide bolt 10 ± 2
Ladder frame bolt 24 ± 2
Piston and connecting rod
Connecting rod cap bolt 5.0 → 20 → +90°
Crankshaft and cylinder block
Crankshaft sensing ring bolt 11 ± 1
Item N⋅m
