3 - 4 3 - 4
3 SPECIFICATIONS
MELSEC-Q
1: Refer to Section 5.2.3 for the program execution management SFC program.
2: The maximum number of sequence steps per block depends on an instruction used for
operation output or a note editing setting. The number of steps (2k steps) indicated in
the table applies when "Unite (United Note)" is selected for note editing. Note that 2k
sequence steps per block may not be secured when "Peripheral (Peripheral Note)" is
selected.
If note editing is not set, 2k sequence steps or more per block may be secured
depending on an instruction used.
REMARKS
The STEP-RUN operation and step trace functions are not available.
