4 - 4
MELSEC-Q
4 SETUP AND PROCED
URES BEFORE OPERATION
Signal name
Terminal
number
Q64AD
Q68ADV
Q68ADI
1
V +
V +
I +
2V
–
CH1
V –
CH1
I –
3
I +
V +
I +
4
CH1
SLD
CH2
V –
CH2
I –
5
V +
V +
I +
6V
–
CH3
V –
CH3
I –
7
I +
V +
I +
8
CH2
SLD
CH4
V –
CH4
I –
9
V +
V +
I +
10
V –
CH5
V –
CH5
I –
11
I +
V +
I +
12
CH3
SLD
CH6
V –
CH6
I –
13
V +
V +
I +
14
V –
CH7
V –
CH7
I –
15
I +
V +
I +
16
CH4
SLD
CH8
V –
CH8
I –
17
A.G. (ANAL
OG GND)
18
FG
34
36
Table of Contents
Default Chapter
2
Safety Precautions
2
Revisions
5
Table of Contents
6
Conformation to the EMC Directive and Low Voltage Instruction
8
About the Generic Terms and Abbreviations
8
Product Structure
9
1 Overview
10
Features
10
2 System Configuration
12
Applicable Systems
12
3 Specifications
14
Performance Specifications
14
Performance Specifications List
14
I/O Conversion Characteristic
15
Accuracy
18
Function List
19
A/D Conversion Methods
19
Maximum and Minimum Values Hold Function
21
I/O Signals for the PLC CPU
21
List of I/O Signals
21
Details of I/O Signals
22
Buffer Memory
25
Buffer Memory Assignment
25
A/D Conversion Enable/Disable Setting (Buffer Memory Address 0: Un\G0)
26
CH Average Time/Average Number of Times
26
Averaging Processing Setting (Buffer Memory Address 9: Un\G9)
27
A/D Conversion Completed Flag (Buffer Memory Address 10: Un\G10)
28
Digital Output Values (Buffer Memory Addresses 11 to 18: Un\G11 to Un\G18)
28
Write Data Error Codes (Buffer Memory Address 19: Un\G19)
29
Setting Ranges (Buffer Memory Addresses 20 and 21: Un\G20 and Un\G21)
29
Offset/Gain Setting Mode (Buffer Memory Addresses 22 and 23: Un\G22 and Un\G23)
30
Maximum and Minimum Values Storage Area (Buffer Memory Addresses 30 to 45: Un\G30 to Un\G45)
30
4 Setup and Procedures before Operation
32
Handling Precautions
32
Part Identification Nomenclature
34
Wiring
36
Wiring Precautions
36
External Wiring
37
Switch Setting for Intelligent Function Module
39
Offset/Gain Settings
41
5 Utility Package (Sw0D5C-Qadu-E)
44
Utility Package Functions
44
Installing and Uninstalling the Utility Package
45
User Precautions
45
Operating Environment
46
Explanation of Utility Package Operation
47
How to Perform Common Utility Package Operations
47
Operation Overview
50
Starting the Intelligent Function Module Utility
52
Initial Setting
54
Automatic Refresh Settings
55
Monitor/Test
57
Monitor/Test Screen
57
Offset/Gain Setting Operation
60
6 Programming
62
Programming Example Using the Utility Package
63
Operating the Utility Package
63
Programming Example
64
Programming Example Without Using the Utility Package
65
7 Troubleshooting
68
Error Code List
68
Troubleshooting
69
When the "RUN" LED Is Flashing or Turned off
69
When the "ERROR" LED Is on or Flashing
69
When the Digital Output Values Cannot be Read
70
Checking the A/D Conversion Module Status Using GPPW System Monitor
71
Appendix
72
Appendix 1. External Dimension Diagram
72
