5 - 156
MELSEC-Q
5 DATA USED FOR POSITIONING CONTROL
Setting item Setting details
Cd.30
Simultaneous starting axis
start data No. (axis 1 start
data No.)
Cd.31
Simultaneous starting axis
start data No. (axis 2 start
data No.)
Cd.32
Simultaneous starting axis
start data No. (axis 3 start
data No.)
Cd.33
Simultaneous starting axis
start data No. (axis 4 start
data No.)
•
Use these data items to specify a start data No. for each axis that has to start
simultaneously.
•
Set "0" to any axis that should not start simultaneously.
Cd.34
Step mode
•
To perform a step operation, use this data item to specify the units by which the
stepping should be performed.
Cd.35
Step valid flag
•
This data item validates or invalidates step operations.
To Next Page
