2 - 5
MELSEC-Q
2 SYSTEM CONFIGURATION
2.3 Applicable system
The QD75 can be used in the following system.
(1) Applicable modules and the number of installable modules
The following table indicates the CPU modules and network modules (for remote
I/O station) usable with the QD75 and the number of installable modules.
Applicable modules Number of installable modules Remarks
Q02CPU
Q02HCPU
Q06HCPU
Q12HCPU
Q25HCPU
Max. 64 modules
Installable in the Q mode
only
(
1)
Q00JCPU Max. 16 modules
Q00CPU
Q01CPU
Max. 24 modules
CPU
module
Q12PHCPU
Q25PHCPU
Max. 64 modules
(
1)
Network
module
QJ72LP25-25
QJ72BR15
QJ72LP25G
QJ72LP25GE
Max. 64 modules
MELSECNET/H remote I/O
station (
2)
1 Refer to the User's Manual (Function Explanation, Program Fundamentals) of the CPU
module used.
2 Refer to the Q Corresponding MELSECNET/H Network System Reference Manual
(Remote I/O Network).
(2) Usable base unit
The QD75 can be installed in any of the I/O slots (
3
) of a base unit.
When installing the QD75, always consider the power supply capacity since a
shortage of the power supply capacity may occur depending on the combination
with the other installed module and the number of installed module.
3 Within the I/O point range of the CPU module and network module (for remote
I/O station).
(3) Compatibility with Multiple PLC system
When using the QD75 in a Multiple PLC system, first refer to the QCPU (Q mode)
User's Manual (Function Explanation, Program Fundamentals).
(4) Supported software packages
The following table lists the compatibility between the systems using the QD75 and
the software packages. GX Developer is required for use of the QD75.
Software version
GX Developer GX Configurator-QP
For use with Q02/Q02H/Q06H/
Q12H/Q25HCPU
Version 4 or more Version 2.00A or more
For use with Q00J/Q00/Q01CPU Version 7 or more Version 2.10L or more
For use with Q12PH/Q25PHCPU Version 7.10L or more Version 2.13P or more
For use in Multiple PLC system Version 6 or more
For use on MELSECNET/H remote
I/O station
Version 6 or more
Version 2.00A or more
