Mitsubishi QD75M1 User Manual

15 - 102
MELSEC-Q
15 TROUBLESHOOTING
15.3.5 MR-J2-Jr detection warning
Classifica
tion of
warnings
Warning
code
LED
display of
the servo
amplifier
Warning name Warning Cause
2141 E1 Over load warning
There is a possibility that
overload alarm 1 (error code:
2050)or 2 (error code: 2051)
may occur.
Load increased to 85% or more of
over load alarm 1 (error code: 2050)
or 2 (error code: 2051) occurrence
level.
2144 E4
Parameter
warning
Parameter outside setting
range.
Parameter value set from QD75M
controller is outside setting range.
2146 E6
Servo emergency
stop warning
EMG1-SG is open.
Emergency stop was made valid.
(EMG1-SG was opened.)
EMG (6 pin) or EMG* (16 pin) in the
SSCNET cable is open.
Fault of connector in the servo
amplifier.
Fault of connector in the QD75.
2147 E7
Controller
emergency stop
warning
An emergency stop signal is
input to the QD75.
A "watchdog error" will be occurred in
the QD75.
Servo
amplifier
warnings
2149 E9
Main circuit of
warning
Servo ON signal is turned ON
while the main circuit power is
off.
Servo ON signal is turned ON while
the main circuit power is off.
