5 - 158
MELSEC-Q
5 DATA USED FOR POSITIONING CONTROL
Setting item Setting details
Cd.36
Step start information
•
During a step operation, this data item determines whether the operation is
continued or restarted.
Cd.37
Skip command
•
To skip the current positioning operation, set "1" in this data item.
Cd.38
Teaching data selection
•
This data item specifies the teaching result write destination.
Cd.39
Teaching positioning data No.
•
This data item specifies data to be produced by teaching.
•
If a value between 1 and 600 is set, a teaching operation is done.
•
The value is cleared to "0" when the QD75 is initialized, when a teaching
operation completes, and when a illegal value (601 or higher) is entered.
Cd.40
ABS direction in degrees
•
This data item specifies the ABS moving direction carrying out the position control
when "degree" is selected as the unit.
To Next Page
