Mitsubishi QD75M1 User Manual

7 - 12
MELSEC-Q
7 MEMORY CONFIGURATION AND DATA PROCESS
Pheripharal devices
(6) Flash ROM write
(Set "1" in Cd.1 with TO
command)
Flash ROM
Servo amplifier
Pr.7Pr.1
to
Pr.11
Pr.24
Pr.43 Pr.57
Pr.10Pr.8
Pr.25 Pr.42
Pr.200
Pr.201
Parameter area (a)
Parameter area (b)
Positioning data area
(No.1 to 600)
Block start data area
(No.7000 to 7004)
PLC CPU
memo area
Monitor data area
Control data area
Buffer memory
(7) Flash ROM request (Write)
QD75
PLC CPU
Servo parameter area
(No.30100 to 30499)
(7) Flash ROM request (Write)
(6) Flash ROM write
(7) Flash ROM request (Write)
Parameter area (a)
Parameter area (b)
Positioning data area
(No.1 to
600)
Block start data area
(No.70
00 to 7004)
Servo parameter area
(No.30100 to 30499)
Parameter area (a)
Parameter area (b)
to
to
to
to
