7 - 15
MELSEC-Q
7 MEMORY CONFIGURATION AND DATA PROCESS
(8) Reading data from buffer memory to peripheral device ( )
The following transmission processes are carried out with the [Module read] from
the peripheral device.
1) The "parameters", "positioning data (No. 1 to 600)" and "block start data (No.
7000 to 7004)" in the buffer memory area are transmitted to the peripheral
device via the PLC CPU.
The following transmission processes are carried out with the [monitor] from the
peripheral device.
2) The "monitor data" in the buffer memory area is transmitted to the peripheral
device via the PLC CPU.
(9) Writing data from peripheral device to buffer memory ( )
The following transmission processes are carried out with the [Module write] from
the peripheral device.
1) The "parameters", "positioning data (No. 1 to 600)" and "block start data (No.
7000 to 7004)" in the peripheral device area transmitted to the buffer memory
via the PLC CPU.
At this time, when [flash ROM automatic write] is set with the peripheral device,
the transmission processes indicated with the following are carried out.
(7) Flash ROM write
To Next Page
