8 - 3
MELSEC-Q
8 OPR CONTROL
OPR sub functions
Refer to section "3.2.4 Combination of QD75 main functions and sub functions" for
details on "sub functions" that can be combined with OPR control. Also refer to "Chapter
12 Control sub functions" for details on each sub function.
[Remarks]
The following two sub functions are only related to machine OPR.
Sub function name Machine OPR Fast OPR Reference
OPR retry function
Section 12.2.1
OP shift function
Section 12.2.2
: Combination possible, : Restricted, : Combination not possible
When an OPR is not required
Control can be carried out ignoring the "OPR request flag" (
Md.31
Status signal: b3) in
systems that do not require an OPR.
In this case, the "OPR parameters (
Pr.43
to
Pr.57
)" must all be set to their initial
values or a value at which an error does not occur.
OPR from peripheral devices
"Machine OPR" and "fast OPR" can be executed from the test mode of the peripheral
device.
Refer to GX Configurator-QP Operating Manual for details on OPR from the peripheral
device.
To Next Page
