9 MAJOR POSITIONING CONTROL
(4) When either of four axes exceeds the speed limit, that axis is controlled with
the speed limit value. The speeds of the other axes are limited at the ratios of
"
Da.8
Command speed".
(Examples)
Axis
Setting item
Axis 1
setting
Axis 2
setting
Axis 3
setting
Axis 4
setting
Pr.8
Speed limit
value
4000.00mm/
min
5000.00mm/
min
6000.00mm/
min
8000.00mm/
min
Da.8
Command
speed
8000.00mm/
min
6000.00mm/
min
4000.00mm/
min
1500.00mm/
min
With the settings shown above, the operation speed in speed control is as
follows.
Axis 1: 4000.00 mm/min (Speed is limited by
Pr.8
).
Axis 2: 3000.00 mm/min (Speed is limited at ratios in axes 1, 2, 3 and 4
command speeds).
Axis 3: 2000.00 mm/min (Speed is limited at ratios in axes 1, 2, 3 and 4
command speeds).
Axis 4: 750.00 mm/min (Speed is limited at ratios in axes 1, 2, 3 and 4
command speeds).
(5) A "No command speed error (error code: 503)" will occur if a current speed
(-1) is set in "
Da.8
Command speed".
(6) The software stroke limit check is not carried out when the control unit is set to
"degree".
