9 - 104
MELSEC-Q
9 MAJOR POSITIONING CONTROL
Positioning data setting examples
The following table shows setting examples when "position-speed switching
control (forward run: position/speed)" is set in positioning data No. 1 of axis 1.
Setting item Setting example Setting details
Da.1 Operation pattern Termination
Set "Termination" assuming the next positioning data will not be
executed. ("Continuous positioning control" and "Continuous path
control" cannot be set in "position/speed changeover control".)
Da.2 Control system
Forward run:
position/speed
Set position-speed switching control.
Da.3 Acceleration time No. 1
Designate the value set in "
Pr.25
Acceleration time 1" as the
acceleration time at start.
Da.4 Deceleration time No. 0
Designate the value set in "
Pr.10
Deceleration time 0" as the
deceleration time at deceleration.
Da.5
Axis to be
interpolated
– Setting not required. (Setting value is ignored.)
Da.6
Positioning address/
movement amount
10000.0
µ
m
Set the movement amount at the time of position control before the
switching to speed control. (Assuming that the "
Pr.1
Unit setting" is
set to "mm".)
Da.7 Arc address – Setting not required. (Setting value is ignored.)
Da.8 Command speed 6000.00mm/min Set the speed to be controlled.
Da.9 Dwell time 500ms
Set the time the machine dwells after the positioning stop (pulse
output stop) by position control to the output of the positioning
complete signal. If the machine is stopped by speed control, the
setting value will be ignored.
Axis 1 Positioning data No. 1
Da.10
M code 10
Set this when other sub operation commands are issued in
combination with the No. 1 positioning data.
Refer to section "5.3 List of positioning data" for information on the setting details.
