10 HIGH-LEVEL POSITIONING CONTROL
POINTS
(1) The "multiple axis simultaneous start control" carries out an operation equivalent to the
"simultaneous start" using the "block start data".
(2) The setting of the "multiple axis simultaneous start control" is easier than that of the "simultaneous
start" using the "block start data".
• Setting items for "simultaneous start" using "block start data"
Positioning start data, block start data, condition data, and positioning data
• Setting items for "multiple axis simultaneous start control"
Positioning data and axis control data
