15 TROUBLESHOOTING
Related buffer memory
address
Axis 1 Axis 2 Axis 3 Axis 4
Set range
(Setting with sequence program)
Remedy
71 221 371 521 0, 1
72
73
222
223
372
373
522
523
• [mm] [inch] [PLS]
–2147483648 to 2147483647
• [degree] 0 to 35999999
With the setting brought into the setting range, turn the
PLC READY signal [Y0] from OFF to ON.
74
75
224
225
374
375
524
525
1 to 10000000 [PLS/s]
1 to 2000000000 [mm/min or others]
• Bring the setting into the setting range.
• Set the speed to the bias speed at start or higher.
(Refer to section 5.2.5)
76
77
226
227
376
377
526
527
1 to 10000000 [PLS/s]
1 to 2000000000 [mm/min or others]
• Bring the setting into the setting range.
• Set the speed to that below the OPR speed.
• Set the value to the bias speed at start or higher.
(Refer to section 5.2.5)
78 228 378 528 0, 1
79 229 379 529 0 to 65535
80
81
230
231
380
381
530
531
0 to 2147483647
82 232 382 532 0, 1, 2, 3
83 233 383 533 0, 1, 2, 3
86 236 386 536 1 to 300
88 238 388 538 0, 1
With the setting brought into the setting range, turn the
PLC READY signal [Y0] from OFF to ON.
