15 TROUBLESHOOTING
Classifi-
cation of
errors
Error
code
LED
indicator
of servo
amplifier
Error name Description Cause
Voltage low in the super capacitor in
the encoder.
Battery voltage low.
Absolute position data in error.
Battery cable or battery fault.
2025 25
Absolute position
lost
Power was switched on for the first
time in the absolute position detection
system.
Super capacitor of the absolute
position encoder is not charged.
Parameter "
Pr.102
Regenerative
brake resistor" setting value error.
Built-in regenerative brake resistor
or regenerative brake option is not
connected.
High-duty operation or continuous
regenerative operation caused the
permissible regenerative power of
the regenerative brake option to be
exceeded.
Power supply voltage is abnormal.
(260VAC or more)
Permissible regenerative power of the
built-in regenerative brake resistor or
regenerative brake option is
exceeded.
Regenerative brake option faulty.
Regenerative transistor faulty.
Regenerative transistor fault
Built-in regenerative brake resistor
or regenerative brake option faulty.
2030 30
Regenerative
error
Cooling fan stopped.
Unusual overheat due to cooling fan
stop.
Small acceleration/deceleration
time constant caused overshoot to
be large.
Servo
amplifier
errors
2031 31 Overspeed
Speed has exceeded the
instantaneous permissible speed.
Servo system is instable to cause
overshoot.
