Setting value
Item
mm inch degree PLS
Pr.43
OPR method
0: Near-point dog method
4: Count method 1) (Zero signal is used.)
5: Count method 2) (Don't used zero signal.)
6: Data set method
Pr.44
OPR direction
0: Positive direction (address increment direction)
1: Negative direction (address decrement direction)
Pr.45
OP address
–2147483648 to
2147483647
×
10
-1
µ
m
–2147483648 to
2147483647
×
10
-5
inch
0 to 35999999
×
10
-5
degree
–2147483648 to
2147483647
PLS
Pr.46
OPR speed
Pr.47
Creep speed
1 to 2000000000
×
10
-2
mm/min
1 to 2000000000
×
10
-3
inch/min
1 to 2000000000
×
10
-3
degree/min
1 to 10000000
PLS/s
OPR basic parameters
Pr.48
OPR retry
0: Don't retry OPR with upper/lower limit switch.
1: Retry OPR with upper/lower limit switch.
Pr.49
OPR dwell time 0 to 65535ms
Pr.50
Setting for the movement amount
after near-point dog ON
0 to 2147483647
×
10
-1
µ
m
0 to 2147483647
×
10
-5
inch
0 to 2147483647
×
10
-5
degree
0 to 2147483647
PLS
Pr.51
OPR acceleration time selection
Pr.52
OPR deceleration time selection
0 to 3
Pr.53
OP shift amount
–2147483648 to
2147483647
×
10
-1
µ
m
–2147483648 to
2147483647
×
10
-5
inch
0 to 35999999
×
10
-5
degree
–2147483648 to
2147483647
PLS
Pr.54
OPR torque limit value 1 to 300%
Pr.56
Speed designation during OP shift 0: OPR speed, 1: Creep speed
OPR detailed parameters
Pr.57
Dwell time during OPR retry 0 to 65535ms
