Mitsubishi QD75M1 User Manual

Appendix - 61
MELSEC-Q
APPENDICES
Buffer memory address
A1SD75 QD75
Items of A1SD75
Axis 1 Axis 2 Axis 3 Axis 1 Axis 2 Axis 3
Pr.129
Pre-alarm data selection 129 229 429
30129 30229 30329
Pr.130
Zero speed 130 230 430
30130 30230 30330
Pr.131
Error excessive alarm level 131 231 431
30131 30231 30331
Pr.132
Optional function 5 132 232 432
30132 30232 30332
Pr.133
Optional function 6 133 233 433
30133 30233 30333
Pr.134
PI-PID control switch-over position droop 134 234 434
30134 30234 30334
Pr.135
Maker setting 135 235 435
30135 30235 30335
Pr.136
Speed differential compensation 136 236 436
30136 30236 30336
Pr.137
Maker setting 137 237 437
30137 30237 30337
Pr.138
Encoder output pulses
30138 30238 30338
Pr.139
Maker setting
30139 30239 30339
Pr.140
Maker setting
30140 30240 30340
Pr.141
Maker setting
30141 30241 30341
Pr.143
Slight vibration suppression control selection 1
30143 30243 30343
Pr.144
Slight vibration suppression control selection 2
30144 30244 30344
Pr.145
Induction voltage compensation
30145 30245 30345
Pr.146
Maker setting
30146 30246 30346
Pr.147
Maker setting
30147 30247 30347
Pr.148
Maker setting
30148 30248 30348
Pr.149
Gain changing selection
30149 30249 30349
Pr.150
Gain changing condition
30150 30250 30350
Pr.151
Gain changing time constant
30151 30251 30351
Pr.152
Ratio of load inertia moment to servomotor
inertia moment 2
30152 30252 30352
Pr.153
Position loop gain 2 changing ratio
30153 30253 30353
Pr.154
Speed loop gain 2 changing ratio
30154 30254 30354
Pr.155
Speed integral compensation changing ratio
30155 30255 30355
Pr.156
Maker setting
30156 30256 30356
Pr.157
Maker setting
30157 30257 30357
Pr.158
Maker setting
30158 30258 30358
Pr.159
Maker setting
30159 30259 30359
Pr.160
Optional function C
30160 30260 30360
Pr.161
Machine resonance suppression filter 2
30161 30261 30361
Pr.162
Maker setting
30162 30262 30362
Pr.163
Maker setting
30163 30263 30363
Pr.164
Maker setting
30164 30264 30364
Pr.165
Maker setting
30165 30265 30365
Pr.166
Maker setting
30166 30266 30366
