Appendix - 65
MELSEC-Q
APPENDICES
Buffer memory address
A1SD75 QD75
Items of A1SD75
Axis 1 Axis 2 Axis 3 Axis 1 Axis 2 Axis 3
Md.100
OPR re-travel value
848
849
948
949
1048
1049
Md.101
Real current value
850
851
950
951
1050
1051
Md.102
Deviation counter value
852
853
952
953
1052
1053
Md.103
Motor rotation speed
854
855
954
955
1054
1055
Md.104
Motor current value
856 956 1056
Md.105
Auto tuning
857 957 1057
Md.105
Load inertia ratio
858 958 1058
Md.105
Position loop gain 1
859 959 1059
Md.105
Speed loop gain 1
860 960 1060
Md.105
Position loop gain 2
861 961 1061
Md.105
Speed loop gain 2
862 962 162
Md.105
Speed integral compensation
863 963 1063
Md.106
Servo amplifier S/W No.
864
865
866
867
868
869
964
965
966
967
968
969
1064
1065
1066
1067
1068
1069
Md.107
Parameter error No. (No.0 to 15)
870 970 1070
Md.107
Parameter error No. (No.16 to 31)
871 971 1071
Md.107
Parameter error No. (No.32 to 47)
872 972 1072
Md.107
Parameter error No. (No.48 to 63)
873 973 1073
Md.107
Parameter error No. (No.64 to 75)
874 974 1074
875 975 1075
Maker setting
876 976 1076
Md.108
Servo status
877 977 1077
Md.109
Regenerative load ratio
878 978 1078
Md.110
Effective load torque
879 979 1079
Md.111
Peak torque ratio
880 980 1080
