6 UTILITY PACKAGE (GX Configurator-DN)
(2) Data to be created with the utility package
The data and files shown below that are created with the utility package are also
processed using GX Developer operation. Figure 6.1 shows which operation
processes which data or file.
<Intelligent function module parameter>
(a) This data is created with the automatic refresh setting, and stored in the
intelligent function module parameter file of the project to be created using
GX Developer.
Program
Parameter
Project
PLC Parameter
Network Parameter
Intelligent Function Module Paramete
(b) Steps 1) to 3) shown in Figure 6.1 are performed using the following
operation.
1) Operating from GX Developer.
[Project]
[Open existing project] / [Save project]/ [Save project as]
2) Operating from the utility parameter setting module selection screen.
[File]
[Open file] / [Save file]
3) Operating from GX Developer.
[Online]
[Read from PLC] / [Write to PLC] "Intelligent function
module parameters"
Or, operate from the utility parameter setting module selection screen.
[Online]
[Read from PLC] / [Write to PLC]
To Next Page
