FUEL SYSTEM
8-3
1.1 Removing fuel injection pump
(1)
Check the match mark location of the fuel injection
pump flange and fuel injection pump installation
flange.
(2) Remove the engine front cover.
(3) Put the match mark on the fuel injection pump gear and
the idler gear.
(4) Remove the fuel injection pump flange bolt and remove
the fuel injection pump from the front plate together
with the flange.
Note: (a) Do not operate the engine without the fuel
injection pump.
(b) When removing the fuel injection pump gear,
loosen the fuel injection pump gear nut with the
pump is installed on the engine.
Removing fuel injection pump (1)
Removing fuel injection pump (2)
Fuel injection pump
gear
Idler gear
