2.SELECTINGINSTALLATIONLOCATION
After getting customer’s approval, select installation location according to following guidelines. 1. Indoor unit • Wherethereisnoobstructiontotheairowandwherethecooledandheatedaircanbeevenly
distributed.
• A solid place where the unit or the wall will not vibrate. • A place where there will be enough space for servicing. (Where space mentioned on the right side
can be secured.)
• Where it is easy to conduct wiring and piping work. • A place where unit is not directly exposed to sunlight or street light. • A place where it can be easily drained. • A place separated at least 1m away from the television or the radio. (To prevent interference to im-
ages and sounds.)
• A place where this unit is not affected by the high frequency equipment or electric equipment. • Avoid installing this unit in place where there is much oil mist. • A place where there is no electric equipment or household. • Installtheindoorunitonthewallwheretheheightfromtheoortothebottomoftheunitismorethan
180 cm.
2.Wirelessremotecontrol • A place where the air-conditioner can receive the signal surely during operating the wireless remote
control.
• A place where it is not affected by the TV and radio etc. • Do not place where it is exposed to direct sunlight or near heat devices such as a stove.
Wireless remote control
Remote control holder
Wood screws
Installation board
6.5 cm minimum from the ceiling
(a) Sleeve
180 cm minimum from the floor
10 cm minimum
from the wall
5 cm minimum
from the wall
3. INSTALLING INSTALLATION BOARD
• Installation board should be installed on the wall which can support the weight of the indoor unit. • Adjustmentoftheinstallationboardinthehorizontaldirectionistobeconductedwithvescrewsinatemporary
tightened state.
• With the standard hole as a center, adjust the board and level it.
Bolt (M6X12)
In case of fixing the unit on concrete wall, use nut
anchor.
Mating mark for level surface
Level position (2 locations)
394
Standard hole
190
40.1
47
130.5 508
130.5
157 455
157
187.5
394
187.5
47
7.6
247.5
6.9
65
Space
50
service
100
55
Piping for Gas 359.5
Piping for Liquid 427.5
Drain hose 530 (ø65)
Unit: mm
55
Installation board
indoor unitSpace for
service
Space for
for service
15 Space
for service
Piping hole (ø65)
Piping hole (ø65)
CAUTION
Improper adjustment of the installation board can cause water leakage.
