Rev: Version 1.2 June 16th, 2022 Page 12 of 26
Standard Operating Mode
Decrease Sensitivity
Press this button to decrease the sensitivity of the Lightning Bug Plus™. When
this button is pressed, the bargraph display (orange LED’s) will show the current
sensitivity level. There are a total of 26 levels of available sensitivity. The factory
default setting is level 12.
Increase Sensitivity
Press this button to increase the sensitivity of the Lightning Bug Plus™. When this
button is pressed, the bargraph display (orange LED’s) will be show the current
sensitivity level.
Determining the Current Sensitivity
The orange LEDs on the top of the Lightning Bug Plus
TM
will always display the
current sensitivity level whenever the unit is powered on. See Table 1 for more
details.
When making adjustments, the LED will brighten to allow easier visualization of
the setting, then dim automatically.
The yellow LED (shaped like a lightning bolt) illuminates whenever the unit has
detected an event and has tripped the shutter. When making adjustments to the
Meter Mode or Frames per Second Mode, this LED flashes at a rate of
approximately 2 times per second.
