9
4-Wire Mode Test Point (TP) Allocation:
Connector 1 = TP 1-32 current source
Connector 2 = TP 1-32 voltage sense
Connector 3 = TP 33-64 current source
Connector 4 = TP 33-64 voltage sense
|
Connector 31 = TP 481-512 current source
Connector 32 = TP 481-512 voltage sense
