9.3.5 Alive Notification [dts4138Alive]

Sent out in a configurable interval.

This Notification is always sent out, as soon as SNMP and the alarm traps are

activated and a destination address is configured.

The Notification sent out contains the following data:

Field Type Size Description Example

dts4138SysStatus Unsigned Int 4 Bytes

Contains the internal

system status

66309

dts4138SysAlarms Byte Array 8 Bytes

64 Bit Alarm flags

1.Byte Bit 0..7

2.Byte Bit 8..15

8.Byte Bit 56..63

FFF870FF.FFFFFFFF

¦ ¦ ¦

¦ ¦ 5.Byte

¦ 2.Byte

1.Byte

9.3.6 Alarm Notification [dts4138Alarm]

Sent out if alarm status changes, i.e. Notification is sent out when an alarm flag is set

or deleted.

This Notification is always sent out, as soon as SNMP and the alarm traps are

activated and a destination address is configured.

The Notification sent out contains the following data:

Field Type Size Description Example

dts4138TrapAlMsgErrorNr Byte 1 Byte No. of the alarm bit (0..63) 3

dts4138TrapAlMsgErrorState Byte 1 Byte

0 = alarm bit was deleted

1 = alarm bit was set

dts4138TrapAlMsgErrorTime

Unsigned

Int

4 Bytes

PC-time in seconds since

01.01.1970 00:00:00

946684805

dts4138TrapAlMsgErrorText Text 59 Bytes Error text

Failure supply 1
