Mobotix M12 - M12 Drilling Templates (Scale 1:1)

3.9 M12 Drilling Templates (Scale 1:1)
SecureFlex wall mount
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
84/92
M12 Camera Manual Part 1
Wall outlet at
upper rim
Note
Make sure that the drilling templates are not scaled nor adjusted to
the paper size when printing.
When printing the PDF file, you should print two pages onto one to
obtain an unscaled printout of the drilling templates.
