Mounting the Camera with Pole Mount (Accessories)
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
2.5.1 Pole Mount (MX-MH-SecureFlex-ESWS)
When mounted to a pole, the camera can be turned or tilted similar to wall installations:
• horizontally: 180°
• vertically: 80°
If the wall mount is rotated by 90degrees, you can also point the camera all the way down:
Pole Mount Dimensions
Tilting the camera when
installed on a pole
• Horizontal: 180°
• Vertical: 80°
-60°
+20°
180°
90°
-90°
+20°
Height: 174mm/6.85in
Width: 140mm/5.51in Depth: 45mm/1.77in
