1.3.2 M15D-Thermal Model Variant
The delivered parts of the M15D-Thermal are slightly dierent from those of the M15 Core
(see
Section 1.3.1, «M15 Core (Base Module)» ):
Changes in the Delivery of the M15D-Thermal
Item Count Part Name
1.2 1 Front element with one thermal image sensor (right) and
additional sensors (installed)
Mounting Supplies
M.11 2 Security clip for sensor or blind modules, red
1.8
1.1
1.10
1.11
1.12
1.7
1.4
1.3
1.6
1.9
1.2
1.5
M.5
M.3
M.2
M.1
M.6
M.7
M.8
M.10
M.11
M.4
1.15
M.9
1.13
1.14
1.19
1.16
1.17
1.18
1.20
