Hamptons
Six Drawer - Wide
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain circumstances,
i.e. if a child attempts to climb up on the furniture or in the event of an earthquake. Accordingly, we recommend
that all furniture is anchored to a wall. We supply a free safety wall anchor with all furniture sold and we
recommend these are used to prevent your product tipping. The fixing device provided should fit most wall types,
but please note that different wall materials may require different fixing devices from those supplied.
HARDWARE SUPPLIED
A B C D
I J K
E
F
bolt
x50
medium screw
x24
small screw
x4
dowel
x26
locking
nut x 50
small screw
x48
handle
x6
long screw
x6
adjuster
x1
40 mm
10 mm
30 mm
CL
CR
DL
DR
L+R
slide rail
x12
L+R
slide rail
x12
Z
Y
wall
anchor x 1
screw
x 1
safety
strap x 1
wall
screw x 1
washer
x 1
XWV
WALL STRAP
L N O
cover
x24
leg
x1
wedge
x12
25 mm
Phillips & Flathead screwdrivers required
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
