Mocka Jack Buffet - Initial Cabinet Structure Assembly; Attaching Bolts to Base Panel; Mounting Slide Rails to Side Panels

Jack Buffet
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
1
2
Insert 8x bolts (C) into panel [1]. Tighten with a screwdriver.
Attach 3x slide rail (F) to panel [5] and secure with 9x screws (E).
Attach 3x slide rail (G) to panel [6] and secure with 9x screws (E).
Tighten with a screwdriver.
