b) Checking the drive function
Always carry out digital trimming before checking the drive function. For more information, consult the
section "Starting up the transmitter" in the Chapter "Checking and setting the digital trimming".
If the throttle/brake lever for the driving function is pulled
towards the handle to the stop, the electrical model has
to accelerate. In a combustion model, the carburettor
must be opened by the gas servo.
When you push the accelerator/brake lever for the
drive function forwards, the model should be braked or
switched to reverse.
After you have checked or set the correct drive and
steering functions, first switch off the receiver, then the
transmitter.
Important!
For a model with a combustion engine, set the rods for the exhaust and brake steering in such a way that
the accelerator/brake servo is not limited mechanically. The trimming regulator for the drive function (see
Figure 2, Number 3) must be in the middle position.
For a model with an electronic drive regulator, the various positions of the operating lever for the drive
functions (forwards, stop, reverse) may need to be programmed into the drive regulator. Additional notes
regarding this can be obtained from the documentation belonging to the drive regulator.
Figure 10
