53
d) “REV” function
This function can be used to change the servo rotation direction of
all three channels (CH1 to CH3) separately. Depending on the instal-
lation position and the steering in the model, it may be necessary to
change the direction of rotation of a servo. For all three channels,
you can select the setting NOR (normal rotation direction) and REV
(reverse rotation direction).
Select the function „REV“ with the programming setting wheel as
already shown in the previous programming examples and activate
it. The number behind „Channel“ flashes.
Now select the channel (CH1, CH2 or CH3) in which you want to
change the rotating direction by turning the programming setting
wheel. Now push the button „Set“ (see figure 3, item 13). The number
behind „Channel“ remains lit now. Below it, the displays flash either
with „NOR“ or „REV“. z
Turn the programing setting wheel to choose between the rotating
directions. Save the desired setting by pushing the programming
setting wheel.
To change the rotating direction of other servos, push the programming setting wheel again and select another servo.
If you do not make any further settings, save the setting by pushing the programing setting wheel. Now push the
button „Return“ (see figure 3, item 10) to get to regular operating mode.
REV
Servo reverse
CHANNEL:
REV
Figure 16
