FEATURES AND BENEFITS - MODEL IPT
Features
1. Heat-treated darkened aluminized steel tubes
2. Polished aluminum reflectors
3. Removable side-access panels on both sides of the
burner box
4. Durable polyester-powder paint
5. Permanently-lubricated combustion blower motor
6. 180 degree-rotating gas valve
7. Sealed burner compartment
8. Flame sensor and ignitor mounted externally to the
combustion chamber
9. Flame observation window on underside of combustion
chamber
10. Gas valve operation light on back panel on the unit
11. Four-trial separate flame sensor
12. System approval for vented and common vented
installation
13. Weatherproof, water-resistant casing
14. ETL design certification
Figure 6.1 - Construction Features
4, 13
8, 11
9
10
3 (not shown)
5
6
Benefits
1. Heat-treated darkening increases both radiant heat output for
more heat near the end of the tube system and eliminates
the scratching and flaking that can occur with painted tubes.
Aluminized steel provides corrosion resistance for longer life.
2. Direct radiant heat from the tubes to the desired area, for
increased comfort over wider areas.
3. Can be removed completely while accessing either side of the
unit.
4. Maintains life-long new appearance.
5. Reduces maintenance.
6. Allows convenient access from either side of the burner box.
7. Allows manifold pressure adjustments during unit operation,
which increases ease of installation and service.
8. Improve service access.
9. Provides a convenient visual check of unit operation from
ground level.
10. Indicates that the combustion blower is operating.
11. Provides reliable ignition.
12. Maximizes installation flexibility.
13. Maximizes application flexibility for both indoor and outdoor
installation.
14. Assures that the unit conforms to national safety standards.
