Modine Manufacturing HD - Dimensional Data - Model IPT

12
9-123.5
TOP VIEW
FRONT VIEW
SIDE VIEW
BACK VIEW
12.39
12.00
1.36
2.61
6.00
4.00
4.00
O 1.000
GAS CONNECTION
O .875
THERMOSTAT
CONNECTION
O .875
LINE VOLTAGE
CONNECTION
10.00
23.12
21.91
11.00
13.58
14.99
6.00
3.65
Straight Tube U-Tube System
Tube Length (ft.) System Length “A” (ft.) System Weight (lb.) System Length “B” (ft.) System Weight (lb.)
20 23 78 13 89
30 33 112 18 132
40 43 146 23 157
50 53 180 28 200
60 63 214 33 225
70 73 252 38 277
Model Shipping Wt. (lb.)
All Burners 43
Table 11.2 - Burner Shipping Weights
Table 11.1 - Tube Systems Data
Figure 11.1 - Casing Dimensions
TOP VIEW
FRONT VIEW
SIDE VIEW
BACK VIEW
12.39
12.00
1.36
2.61
6.00
4.00
4.00
O 1.000
GAS CONNECTION
O .875
THERMOSTAT
CONNECTION
O .875
LINE VOLTAGE
CONNECTION
10.00
23.12
21.91
11.00
13.58
14.99
6.00
3.65
B
A
11"
28"
Center-to-center of tubes = 16 inches.
14"
Figure 11.2 - Burner and Tube System Dimensions
DIMENSIONAL DATA - MODEL IPT
