ACCESSORIES
Table 19.1 - Field Installed Accessories
Feature
Model
HD HDB PDP BDP PTP BTP
Cabinet and Air Mover
Vertical Deflector Blades - Allows directional discharge air control in the left and right
directions.
• • • • • •
Downward Air Deflector Hoods - Available in 30°, 60°, and 90° configurations these
deflector hoods enable the unit to be mounted higher while still providing heat to the building
occupants. Refer to page 16 for further details.
• • • • • •
Vibration Isolation Kit - Minimizes unit vibration transmission to the building structure. • •
Pipe Hanger Adapter Kits - Allows the unit to be suspended by 3/4" pipe from the standard
3/8" holes found in the top of the unit.
• • • •
Discharge Transition for Polytube - Allows for the connection of polytube (not included) to
the discharge of the unit.
• • •
Blower Enclosure with or without Filter Rack - Totally encases the motor and blower
assembly. Optional filters provide filtering of the air prior to entering the heater.
• • •
Discharge Velocity Generating Nozzle - Four varieties of velocity generating nozzles
allow for increased application flexibility. These nozzles increase mounting height while also
directing the airflow to the desired locations. Refer to pages 20-21 for further details.
• •
Belt Guard - Provides protection for building occupants as well as service people from the
drive belt and sheaves.
• •
Controls
Natural Gas to Propane Gas Conversion Kit - Provides all required parts as well as
instructions to convert a natural gas unit to propane gas.
• • • • • •
Single or Two-Stage Room Thermostats - See Table 19.2 for details. • • • • • •
Room Thermostat Guard - Clear plastic for room thermostats. Guard is locking type and
comes with two keys.
• • • • • •
Summer/Winter Switch - Allows a choice of unit fan operation. In the summer position, the
fan runs continuously for ventilation while allowing the gas controls to fire on a call for heat
from the thermostat. In the winter position, the fan runs intermittently on a call for heat from
the thermostat.
• • • • • •
Stepdown Transformers - Used to operate propeller units on 208/230/460/575V/3Ph
supply voltage. Also may be required for control circuits for blower units. Refer to Table 18.1
for further selection details.
• • • • • •
Control Relays - This single pole single throw relay consists of a 24V coil with a maximum
contact rating of 18 amps at 115V.
• • • • • •
Gas Pressure Regulator - Fisher Type S-100, 3/4 inch pressure regulator for 1/2 to 50 psi
inlet pressure capacity, 30 MBH to 400 MBH.
• • • • • •
Energy Saver Kit - Used to lower total energy costs by reducing stratified air in high
mounting height applications. This kit consists of a controller with a SPDT (16A @ 120V)
switch and a temperature rage of 30° - 100°F.
• • • • • •
Building Managment System - The Modine Building Management System (BMS) Board
installed in this unit provides an RS485 interface between the unit heater and existing
building networks that employ a BACnet or Modbus protocol.
• • • • •
Table 19.2 - Field Installed Thermostats
Single-Stage
Thermostats
Type Description
Room
Thermostat
Thermostat, Modine Pro1 T-501M: 50-90°F, Non-programmable Thermostat includes 3 swap panels:
1.) Fan: On/Auto, System: Heat/Off/Cool, 2.) Fan: On/Auto, System: On/Off, 3.) System: On/Off
Two-Stage
Thermostats
Room - Digital Thermostat, Modine Pro1 T-715M: 41-95°F, Heat/Auto/Off, Fan Auto/On, 7-day programmable
Room - WiFi WiFi Thermostat, Modine Pro1 T855iSH: 41-95°F, 7-day prog, wifi, hardwire only
Duct Johnson Controls A350 Electronic Temp Control with Sensor and S350 Stage Adder (Blower units only)
Guard Room Thermostat Guard, Modine Pro1 T-150, Clear Plastic, Tumbler Lock with two keys
