15
6-189.18
BLOWER PERFORMANCE DATA - MODEL BDP
Table 15.1 - Power Code Description — Blower Model BDP j
j For selection of correct Power Code, refer to the Tables on pages 16-17.
Power Code
150 175 200 250 300 350 400
Voltage Phase HP Drive HP Drive HP Drive HP Drive HP Drive HP Drive HP Drive
01 115 1 1/4 191 - - 1/4 212 - - - - - - - -
02 230 1 1/4 191 - - 1/4 212 - - - - - - - -
07 575 3 1/4 197 - - 1/4 213 - - - - - - - -
08 208-230/460 3 1/4 191 - - 1/4 212 - - - - - - - -
09 115 1 1/3 191 1/3 95 1/3 212 1/3 203 3/4 205 1 107 1-1/2 105
10 230 1 1/3 191 1/3 95 1/3 212 1/3 203 3/4 205 1 107 1-1/2 105
15 575 3 1/3 197 1/3 96 1/3 213 1/3 204 3/4 205 1 255 1-1/2 180
16 208-230/460 3 1/3 191 1/3 95 1/3 212 1/3 203 3/4 205 1 255 1-1/2 180
17 115 1 1/3 95 1/2 96 1/3 102 1/2 204 1 205 1-1/2 105 - -
18 230 1 1/3 95 1/2 96 1/3 102 1/2 204 1 205 1-1/2 105 - -
23 575 3 1/3 96 1/2 96 1/3 101 1/2 204 1 157 1-1/2 180 2 210
24 208-230/460 3 1/3 95 1/2 96 1/3 102 1/2 204 1 157 1-1/2 180 2 210
25 115 1 1/2 96 3/4 192 1/2 101 3/4 205 1-1/2 106 1-1/2 100 - -
26 230 1 1/2 96 3/4 192 1/2 101 3/4 205 1-1/2 106 1-1/2 100 - -
31 575 3 1/2 96 3/4 192 1/2 101 3/4 205 1-1/2 108 1-1/2 210 3 111
32 208-230/460 3 1/2 96 3/4 192 1/2 101 3/4 205 1-1/2 108 1-1/2 33 3 111
33 115 1 3/4 38 1 192 3/4 16 1 205 - - - - - -
34 230 1 3/4 38 1 192 3/4 16 1 205 - - - - - -
39 575 3 3/4 38 1 256 3/4 16 1 157 2 108 2 210 5 207
40 208-230/460 3 3/4 38 1 256 3/4 16 1 157 2 108 2 210 5 207
41 115 1 1 38 1-1/2 193 1 16 1-1/2 105 - - - - - -
42 230 1 1 38 1-1/2 193 1 16 1-1/2 105 - - - - - -
47 575 3 1 254 1-1/2 198 1 178 1-1/2 180 3 111 3 111 2 180
48 208-230/460 3 1 254 1-1/2 198 1 178 1-1/2 180 3 111 3 111 2 180
49 115 1 1/4 13 - - 1-1/2 105 - - 1-1/2 105 - - - -
50 230 1 1/4 13 - - 1-1/2 105 - - 1-1/2 105 - - - -
55 575 3 1/4 14 2 80 1-1/2 180 2 108 1-1/2 110 5 207 3 112
56 208-230/460 3 1/4 13 2 80 1-1/2 180 2 108 1-1/2 180 5 207 3 112
57 115 1 3/4 96 3/4 96 1/4 24 3/4 204 - - - - - -
58 230 1 3/4 96 3/4 96 1/4 24 3/4 204 - - - - - -
63 575 3 3/4 96 3/4 96 1/4 25 3/4 204 - - 2 180 5 111
64 208-230/460 3 3/4 96 3/4 96 1/4 24 3/4 204 - - 2 180 5 111
65 115 1 - - 1-1/2 79 1/3 24 1-1/2 23 - - - - - -
66 230 1 - - 1-1/2 79 1/3 24 1-1/2 23 - - - - - -
71 575 3 - - 1-1/2 80 1/3 25 1-1/2 177 - - 5 181 - -
72 208-230/460 3 - - 1-1/2 80 1/3 24 1-1/2 177 - - 5 181 - -
73 115 1 - - - - 1/2 25 - - - - - - - -
74 230 1 - - - - 1/2 25 - - - - - - - -
79 575 3 - - - - 1/2 25 - - - - - - - -
80 208-230/460 3 - - - - 1/2 25 - - - - - - - -
81 115 1 - - - - 3/4 101 - - - - - - - -
82 230 1 - - - - 3/4 101 - - - - - - - -
87 575 3 - - - - 3/4 101 - - - - - - - -
88 208-230/460 3 - - - - 3/4 101 - - - - - - - -
89 115 1 - - - - 1-1/2 23 - - - - - - - -
90 230 1 - - - - 1-1/2 23 - - - - - - - -
95 575 3 - - - - 1-1/2 177 - - - - - - - -
96 208-230/460 3 - - - - 1-1/2 177 - - - - - - - -
